Parameter Name

AWT100-4G

AWT100-NB

AWT100-2G

AWT100-LoRa

AWT100-LW

Working frequency

LTE-FDD B1 B3 B5 B8

LTE-TDD B34 B38 B39 B40 B41

CDMA B1 B5 B8

GSM  900/1800M

H-FDD B1 B3 B8 B5 B20

GSM 850

EGSM 900

DCS 1800

PCS 1900

LoRa 460 510MHz

Transmission rate

LTE-FDD

Maximum downlink rate 150Mbps

Maximum uplink rate 50Mbps

LTE-TDD

Maximum downlink rate130Mbps

Maximum uplink rate 35Mbps

CDMA

Maximum downlink rate 3.1Mbps

Maximum uplink rate 1.8Mbps

GSM

Maximum downlink rate 107Kbps

Maximum uplink rate 85.6Kbps

Maximum downlink rate 25.2Kbps

Maximum uplink rate 15.62Kbps

GPRS

Maximum downlink rate 85.6kbps

Maximum uplink rate 85.6kbps

LoRa  62.5kbps

Downlink

RS485 Communication

Uplink

4G Communication

NB-IoT Communication

2G Communication

LoRa Communication

SIM card voltage

3V，1.8V

/

Working current

Static power：≤1W，Transient power consumption：≤3W

Static power：≤0.5W，

Transient power consumption：≤1W

Antenna interface

50Ω/SMA（Faucet）

Serial port type

RS-485

Baud rate

4800bps、9600bps、19200bps、38400bps（default 9600bps）

Operating Voltage

DC24V或AC/DC220V^①

Operating temperature

-10℃～55℃

Storage temperature

-40℃～85℃

Humidity range

0～95% Non-condensing
